Features and BenefitsSpecificationsWhat's IncludedDocumentsFeatures and Benefits Highest Output in its Class! (250 A at 28 VDC). Weld longer on high-end applications. Large, Digital Front Panel with Built-in Digital Timers Menu Enables operator to preset voltage and wire feed speed. Standard run-in, pre/postflow, burnback, spot/delay (stitch) timer menu. Auto Gun Detect™ Miller’s Auto Gun Detect allows operator to simply pull trigger on MIG gun, spool gun or push/pull gun. Automatically detects and recalls the voltage, wire feed speed and timer of the active gun. Push-Pull Gun Direct Connect Compatible with Spoolmate 200 Series spool gun with wire feed speed control on the gun. This saves time by reducing trips back to the machine. Also compatible with more industrial Spoolmatic 15A or 30A spool gun. Angled, Dual-Gear Driven, Cast Aluminum Drive System Features no-tool, quick-change reversible drive rolls and an easy-to-set, scaled tension knob. EZ-Change™ Low Cylinder Rack Allows operators to easily roll cylinders on and off of rack – no need to lift cylinders. EZ-Access™ Consumable Compartment and Parameter Chart. Set weld parameters right the first time with convenient new flip-down compartment that provides fast access to parameter chart and consumables. Larger Work Area Now with longer 15-ft M-25 gun. Specifications PROCESSES Flux Cored (FCAW) MIG (GMAW) GENERAL SPECIFICATIONS Title Millermatic® 252 MIG Welder 230/460/575V Industries Interests Racing / Customizing / Restoring DIY / Home Hobbyist Farm and Ranch Manufacturing Metal Art / Sculptures Education / Training Commercial Truck and Trailer Fabrication Maintenance and Repair – In Plant Material Thickness Mild Steel 22 ga. (0.9 mm) – 1/2 in. (13 mm) Aluminum 14 ga. (1.9 mm) – 3/8 in. (9.5 mm) Weldable Metals Aluminum Stainless Steel Steel Input Voltage 208 V 220/230/240 V Input Phase 1-Phase Input Hz 60 Hz Current Type DC Rated Output 200 Amps at 24 VDC, 60% duty cycle,250 Amps at 26.5 VDC, 40% duty cycle Max Open Circuit Voltage 38 VDC Amperage Range Amperage Min Max 30 A – 300 A Wire Feed Speed IPM Range 50 IPM – 700 IPM MMin Range 1.3 m/min – 17.8 m/min Wire Diameter Solid Steel 0.023 in – 0.045 in Stainless Steel 0.023 in – 1.2 mm Flux Cored 0.03 in – 0.045 in Solid Steel 0.6 mm – 1.2 mm Stainless Steel 0.6 mm – 1.2 mm Flux Cored 0.8 mm Spool Size 12 in (305 mm) Portability Running Gear / Cart (Standard) Weld Output CV Net Width 19 in Net Height 30 in Net Length 40 in Net Weight 205 lbs Warranty 3 Years Miller’s True Blue Warranty What's Included Millermatic® 252 15 ft. (4.5 m) 250-amp MDX™-250 MIG gun w/ Bernard® AccuLock™ MDX consumables for .030/.035 in. (0.8/0.9 mm) wire 10 ft (3 m) industrial power cord 10 ft (3 m) work cable and clamp Argon mix regulator/flow gauge and hose Factory-installed lowered runningt gear/cylinder rack .030/.035 in. reversibledual-groove drive rolls Extra contact tips NOT INCLUDED Your local welding distributor can provide shielding gas, additional welding wire and a full product offering. Shielding gas (for welding with solid wire [GMAW]) Flux cored drive rolls (for welding with flux cored wire [FCAW]) Spool Gun (for welding aluminum) Welding wire Personal safety products (helmet, gloves) Documents Spec Sheet (ENG) Spec Sheet (ESP) SKU: 907322 Categories: Brands, Equipment, Mig Welder Accessories, Mig Welders, MIG Welding (GMAW), Miller Electric Tag: millermatic Brand: Miller
