Features and BenefitsDocumentsSpecificationsWhat's IncludedFeatures and Benefits Broad output range of 25 – 130 Amps. Allows you to weld up to 3/16 in. steel with flux-cored wire. Four output voltage settings Four voltage ranges allow you to adjust the arc for different thicknesses. Factory-installed gas solenoid Easy for you to change from flux-cored wire to MIG welding. Built-in contactor Keeps wire electrically “cold” until trigger is pulled which gives you ease of use. Spool hub assembly accommodates 4- or 8- inch spools Offers you flexibility to use small or large spools of wire to better suit your welding needs. Durable feed head with quick-release drive roll tension lever. Positive feed with adjustable tension gives you easy access to thread new wire. Self-resetting thermal overload. Protects power transformer from thermal overload to provide you maximum reliability. Documents Spec Sheet (ENG) Specifications PROCESSES Flux Cored (FCAW) MIG (GMAW) Title Handler® 125 MIG Welder Material Thickness 24 ga (0.8 mm) – 3/16 in Weldable Metals Steel Stainless Steel Input Voltage 110/115/120 V Input Phase 1-Phase Current Type DC Rated Output 80 A @ 25% Max Open Circuit Voltage 28 VDC Amperage Range 25 A – 130 A Wire Feed Speed 88 IPM 545 IPM Weld Output CV Net Width 10 in Net Height 13.5 in Net Length 19.4 in Net Weight 57.5 lbs Warranty 3 Years What's Included Comfortable 8 ft. (2.4 m) H100F2-8 gun with liner for .030-.035 in. (0.8 -0.9 mm) diameter wire. Work cable with clamp (2) – 0.030 (0.8 mm) contact tips Power cord with molded plug Weld set -up chart Owner’s manual with installation, operation and maintenance guidelines. SKU: 500573 Categories: Brands, Hobart Welding Products, MIG Welding (GMAW) Brand: Hobart
